NU316118S | Switch, New Unica, mechanism, 1-pole 1-way, 16AX, 1 module, screw terminals, untreated, IP4X, white
Original price was: 147.40 EGP.120.87 EGPCurrent price is: 120.87 EGP.
NU320118SC | One way switch, New Unica, 10 AX, 2 module, white
Original price was: 181.50 EGP.148.83 EGPCurrent price is: 148.83 EGP.
NU316318 | Switch, New Unica, mechanism, 1-pole 2-way, 16AX, 1 module, screw terminals, untreated, IP4X, white
Original price was: 210.10 EGP.172.28 EGPCurrent price is: 172.28 EGP.
In stock
Description
The Mureva Styl surface mounted box is a robust and waterproof IP55 device when associated with a Mureva Styl box cover. Easy handling with its large cabling space. This product can be used indoor as well as outdoor. its dimensions are : 54 mm height, 76 mm width, 54 mm and 76 mm length.
Additional information
| Main Category | New Unica White |
|---|---|
| Device presentation | Mechanism |
| Sub Category | Light switches |
| Device application | Light control |
| Colour | White |
| Network type | alternating current |
| Network frequency | 50/60 Hz |
| Colour tint | White (RAL 9003) |
| Insulation resistance | > 5 MΩ at 500 V |
| Materials | ASA+PC: Mechanism cover ABS(Acrylonitrile Butadiene Styrene): Mechanism cover |
| surface layer | Shiny |
| Product Certifications | CE AENOR EAC NF VDE |
| Depth of integration | 21.15 mm |
| Depth | 34.25 mm |
| the offer | 22,5 mm |
| Height | 45 mm |
| Net weight | 0,0179 kg |
| Surface treatment | Untreated |
| Rated current: | 16 amps |
| Opening distance | > 3 mm |
| Operator | swing |
| Marking | Without Marking |
| Technology type | Electromechanical |
| swing number | 1 |
| Key function | One outlet, two directions |
| Packing type | flow-pack packaging machine |
| Environmental feature | Oil Liquid Soap Alcohol Gasoline Bleach Liquid Cleaning Fluids Acetone UV Resistant |
| Criteria | EN 60669-1 LV Directive EMC Directive |
| Unit Type of Package 1 | PCE |
| Number of Units in Package 1 | 1 |
| Package 1 Height | 2,300 cm |
| Package 1 Width | 3,500 cm |
| Package 1 Length | 4,500 cm |
| Package 1 Weight | 20,000 g |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 20 |
| Package 2 Height | 8,000 cm |
| Package 2 Width | 18,500 cm |
| Package 2 Length | 18,500 cm |
| Package 2 Weight | 482,000 g |
| Unit Type of Package 3 | S02 |
| Number of Units in Package 3 | 40 |
| Package 3 Height | 15,000 cm |
| Package 3 Width | 30,000 cm |
| Package 3 Length | 40,000 cm |
| Package 3 Weight | 1,286 |
| sustainable display case | Product of the Green Premium range |
| Mercury free | Yes |
| Sustainable packaging | Yes |
| Environmental Disclosure | Product environmental profile |
| Circular profile | No special recycling required. |
| Brand | Schneider Electric |
